Non-Asbestos Beater Sheet: High-Performance Industrial Gasket Material

Description:

"TOP SEALING Non-Asbestos Beater Sheet: Engineered for Superior Gasket Performance"

This high-performance medium-density material is crafted from a blend of synthetic emulsion, plant fiber, and inorganic fillers. Designed for use as a soft gasket, it combines cellulose and aramid fibers with a reinforced inorganic filler, ensuring exceptional sealing under medium flange loads.

The unique formulation allows the gasket to expand appropriately when exposed to oil, compensating for any machining precision shortfalls and enhancing self-sealing capabilities. Available in vulcanized non-asbestos beater sheets with smooth surfaces, it can also be equipped with anti-stick or graphite coatings for added functionality.

Boasting excellent compressibility and a high coefficient of resilience, this product is the epitome of quality and reliability in sealing solutions for industrial applications.

Non-Asbestos Beater Sheet: High-Performance Industrial Gasket Material

Detail Image

Product Details

1. Used in Automobile, farm machinery, motors, engineering etc.

2. it can be used in oil system and water supply system at temperature 150 deg.

More Styles

Application Data
Advantages
Video
Comparison Vision
Data Unit Non Asbestos Beater Sheet  Vulcanized non-asbestos beater sheet
Color Grey, Black, other color on request
Dendisty G/CM3 0.9-1.1 1.2-1.4
Thickness MM 0.3-2.0MM 0.3-2.0MM
Width MM  500MM; 1000MM
Length MM 500MM; 1000MM; 1200MM; 1500MM
Tensile strength ≥Mpa 12.7
Compressibility % 15±5
Recovery ≥% 45
Stress relaxation ≤% 35
Weight increase (in oil) ≤% 35
Thickness increase (in oil) ≤% 15

Simply you can wholesale Non-Asbestos Beater Sheet: High-Performance Industrial Gasket Material direct from manufacturers.

Professional Manufacturer

SUNPASS SEALING i a leading manufacturer in Sealing and Insulation in China. Production & Service 7*24 . Sunpass is a famous Chinese brand and Non-Asbestos Beater Sheet: High-Performance Industrial Gasket Material suppliers known by the world since 2000.
