Non-Asbestos Rubber Sheet: Durable and Safe Sealing Solution for Industrial Applications

Description:

"Premium Non-Asbestos Rubber Sheet: Engineered for Superior Sealing Performance"

"Introducing the TOP SEALING Non-Asbestos Rubber Sheet, crafted from a blend of special heat-resistant fibers, high-temperature packing materials, and natural rubber. Through a meticulous process of heat and compression molding, we've created a product that offers exceptional sealing solutions for a variety of industries.

Our Tenglong/Sunpass non-asbestos sheets are specifically designed for applications across petrochemical, chemical, and industrial sectors where precise sealing is paramount. We offer a comprehensive selection of grades, ensuring that our customers can find the perfect fit for their specific needs, no matter the application."

Non-Asbestos Rubber Sheet: Durable and Safe Sealing Solution for Industrial Applications

Detail Image

Product Details

Max. Lasting Temperature	Max. Short-term Temperature	Max. Pressure	Compressibility	Recovery	Spec. Leakage Rate	Flexibility
150℃/302℉	200℃/392℉	60 bar	5 – 15%	≧45%	≈0.1 mg/(s.m)	No cracks and breaks
200℃/392℉	360℃/680℉	80 bar	5 – 15%	≧50%	≈0.1 mg/(s.m)
250℃/482℉	400℃/752℉	100 Bar	5 – 15%	≧50%	≈0.06 mg/(s.m)
300℃/572℉	400℃/752℉	100 Bar	5 – 15%	≧50%	≈0.04 mg/(s.m)
350℃/662℉	450℃/842℉	120 bar	5 – 15%	≧50%	≈0.04 mg/(s.m)
400℃/752℉	450℃/842℉	130 bar	5 – 15%	≧60%	≈0.02 mg/(s.m)
450℃/842℉	480℃/896℉	130 bar	5 – 15%	≧60%	≈0.04 mg/(s.m)

More Styles

Application Data

Advantages

Video

Comparison Vision

Max. Lasting Temperature	Weight	Thickness	Reinforcement	Coating	Size	Color
150℃/302℉	118.56lb/ft3 (1.9g/cm3)	0.02-0.3inch (0.5-6mm)	Stainless Steel	Graphite, Silicon Rubber	1270 x 1270mm, 1270 x 3810mm, 1500 x 1000mm, 1500 x 1350mm, 1500 x 1500mm, 1500 x 2000mm, 1500 x 3000mm, 1500 x 4100mm, 1500 x 4600mm, 2700 x 3810mm.	Red, Green, Yellow, Blue, Black, Grey
200℃/392℉
250℃/482℉
300℃/572℉
350℃/662℉
400℃/752℉
450℃/842℉
