Enhanced Durability: Metal Corrugated Gasket for Industrial Sealing Solutions

Description:

SUNPASS Metal Kamprofile Serrated Gaskets: Unmatched Reliability for Challenging Environments

SUNPASS Metal Kamprofile Serrated Gaskets are engineered to excel in the most demanding applications, including superheated steam, high-pressure hydrocarbon, and chemical services. These exceptional gaskets are a staple in both conventional Electric Power Plants and Nuclear Power Plants, as well as in the chemical and petrochemical industries.

Featuring a solid core with precisely machined grooves and a soft material facing—such as graphite, PTFE, or other specialized materials—our gaskets are crafted from premium stainless steels like SS304L, SS316L, and SS321, ensuring durability and performance in even the most challenging conditions.

Enhanced Durability: Metal Corrugated Gasket for Industrial Sealing Solutions

Detail Image

Product Details

Product	Materials	Surface Pressure(N/mm2)
		T=20℃		T=300℃
		min	max	min	max
MCG	Carbon Steel	120	600	130	390
	Stainless Steel/Graphite	15	180	20(1)	150(1)
	Stainless Steel/PTFE	15	180	20(1)	150(1)
	Aluminium/Mineral Fibre	30	80	_	_
	Copper/Mineral Fibre	35	110	45	90
	Carbon Steel/Mineral Fibre+PTFE	45	150	60	125
	Steel/Mineral Fibre	35	150	45	125
	Carbon Steel/Mineral Fibre	75	150	70	125
	Stainless Steel/Graphite	20	180	25	150

More Styles

Application Data

Advantages

Video

Comparison Vision

Simply you can wholesale Enhanced Durability: Metal Corrugated Gasket for Industrial Sealing Solutions direct from manufacturers.
