High-Performance Fiber Glass Tape with Graphite

Description:

Introducing the TOP SEALING FIBER GLASS GRAPHITE TAPE, a high-performance solution with an exceptional graphite coating. This tape is engineered to enhance abrasion resistance and withstand extreme temperatures, offering continuous use at 1000°F (537°C) and extended performance at 1112°F (600°C), even tolerating higher temperatures for short durations.

Suitable for demanding environments, this tape thrives in hot, dry conditions and aggressive settings where untreated fabrics may be prone to damage due to flexing. The tape's high-temperature capabilities make it an ideal choice for protecting industrial wires, cables, hoses, tubes, and pipes. It also serves as a reliable source of thermal insulation and personnel protection.

Furthermore, the TOP SEALING FIBER GLASS GRAPHITE TAPE can be utilized as a gasket or seal, ensuring a secure and efficient seal in various applications.

High-Performance Fiber Glass Tape with Graphite

Detail Image

Product Details

Description Item E-Glass C-Glass
Chemical Composition SiO2  58-63% 64-68%
CaO 21-23% 11-15%
Al2O3 10-13% 3-5%
MgO 2-4% 4-6%
B2O3 - 0-6%
Chemical Resistance-14mm fiber; % weight loss after 1 hr boil in H2O 0.2 0.13
1.04 NH2SO4 0 0.1
0.1 NaOH 0.2-0.6 2.28
Temperature Softening Point  892℃/1635℉ 748℃/1380℉
Coefficient of thermal expansion-in/in/ °F x 10-7 2℃/29℉ 5℃/40℉
Specific Gravity (bare fiber) 2.63 2.49
Pristine Tensile Strength, psi 510,000 400,000
