The Quad-Truck 24-Carrier Square Machine is an innovative material handling system designed for efficiency and precision. Equipped with four powerful trucks and a 24-carrier square grid, it optimizes space utilization and sorting capabilities. This versatile system is ideal for various industries, streamlining operations and enhancing productivity. Its robust construction ensures long-lasting performance, making it a reliable choice for your logistics needs.
| Machine Size(mm) | 1700*1700*2300 |
| Working Table Size(mm) | 1200*1200 |
| Motor Power | 1.5kw(50Hz 380v) |
| Carrier Speed | 25m/minute |
| Spindle Speed | 280RPM/minute |
| Weaving Range | 8*8--40*40 |
| Weaving Speed | Stepless Control |
| Yarn Tube Volume | 68*130 68*160 |
| Proposed Hammer Choice | 0.4kg 0.6kg |
| Whole Machine Weight | 1300kg |
| Main Horn | Using wear resistant ductile iron |
| Remarks: The backplane is designed for outside circle-shaped with flat and gear. Waste drops down automatically. Especially suited for multi-dust material such as graphite and so on. | |
Simply you can wholesale Quad-Truck 24-Carrier Advanced Square Sortation System direct from manufacturers.
SUNPASS SEALING i a leading manufacturer in Sealing and Insulation in China. Production & Service 7*24 . Sunpass is a famous Chinese brand and Quad-Truck 24-Carrier Advanced Square Sortation System suppliers known by the world since 2000.
