TOP SEALING PTFE Graphite Impregnated Carbon Packing, STYLE 6900HG, is meticulously crafted from high-carbon continuous yarns that are softened and then braided. It is impregnated with proprietary lubricants and infused with graphite particles, which fill voids, serve as a break-in lubricant, and effectively block leakage. STYLE 6900HG is specifically designed for use in pumps or valves that operate under high pressure and high temperature conditions.
Regular:3m, 8m, 1kg, 1 pound, 2.5kg, 2.5 pound, 5kg, 5 pound,10kg, 10 pound.
Other packages are available on request
Not suitable for:Highly concentrated corrosive acids.
|
|
|
|
|
|
Pressure: bar |
30 |
— |
300 |
|
Speed: m/s |
15 |
— |
— |
|
PH Range |
2-12 |
||
|
Temp.℃ |
-40 to +400 |
||
|
Density: (g/cm³) |
1.4 |
||
|
Size |
1/8"-2" |
||
|
3mm-50mm |
|||
Carbon packing, impregnated with PTFE and graphite in the STYLE 6900HG, is a versatile sealing solution suitable for a variety of industrial applications. It can be effectively utilized in pumps, boiler feed pumps, valves, mixers, refiners, and other equipment across a wide range of industries, including but not limited to the pulp and paper sector. This high-performance packing is designed to withstand demanding conditions and provide reliable sealing performance.
Simply you can wholesale PTFE Graphite-Impregnated Carbon Packing for High-Performance Sealing direct from manufacturers.
1. Capable of Withstanding High Pressure
2. Resistant to Extreme High Temperatures
3. Compatible with a Wide Range of Media
SUNPASS SEALING i a leading manufacturer in Sealing and Insulation in China. Production & Service 7*24 . Sunpass is a famous Chinese brand and PTFE Graphite-Impregnated Carbon Packing for High-Performance Sealing suppliers known by the world since 2000.
