PTFE-Enhanced Braided Seal for Superior Fluid Retention

Description:

**SUNPASS PTFE Braided Seal AP00001: Advanced Non-Stick Sealing Solution**

- **Innovative Construction**: Crafted from a specially formulated, inert reinforced fiber yarn, our SUNPASS PTFE Braided Seal AP00001 is impregnated with PTFE and an inert resin, ensuring a durable and non-stick surface that resists a wide range of chemicals and media.

- **Customizable Material Options**: We offer the flexibility to choose from various fiber materials to suit specific application requirements, ensuring optimal performance and compatibility.

- **SUNPASS PTFE Braided Seal with Silicon Core**: Engineered for tanks handling aggressive cargoes under an inert gas blanket, this seal features a silicon core that enhances its elasticity. This improvement allows for a more secure seal, even in challenging conditions.

- **Designed for Reliability**: Our seal is meticulously designed to provide reliable performance in demanding environments, ensuring the safe and efficient containment of aggressive cargoes.

PTFE-Enhanced Braided Seal for Superior Fluid Retention

Detail Image

Product Details

Chemical Properties：
Inert to media in the range PH 0-14 ( except for HF and certain fluorine containing compounds ) and totally compatible with a full range of cargoes including chemicals, petroleum products and foodstuffs.

Service Capabilities：
Tank maximum pressure: 2 bar Maximum temperature: +120C Minimum temperature: -50C

Other Material
1. With silicone core
2. Pure PTFE material
3. Graphite-PTFE material

More Styles

Application Data

Advantages

Video

Comparison Vision

Surpass Code	Size
AP00001	14MM X 14MM SECTION X 1625MM LENGTH
AP00002	14MM X 14MM SECTION X 1630MM LENGTH
AP00003	14MM X 14MM SECTION X 1650MM LENGTH
AP00004	10MM X 14MM SECTION X 1625MM LENGTH
AP00005	10MM X 14MM SECTION X 1630MM LENGTH
AP00006	10MM X 14MM SECTION X 1650MM LENGTH
AP00007	10MM X 15MM SECTION X 1650MM LENGTH
AP00008	10MM X 10MM SECTION X 1650MM LENGTH
AP00009	14MM X 12MM SECTION X 1650MM LENGTH
AP00010	10MM X 15MM SECTION X 50METERS LENGTH
AP00011	14MM X 14MM SECTION X 50METERS LENGTH
AP00012	14MM X 14MM SECTION X 50METERS LENGTH

Simply you can wholesale PTFE-Enhanced Braided Seal for Superior Fluid Retention direct from manufacturers.
