High-Performance Ceramic Fiber Insulation Board

Description:

1. **TOP SEALING Ceramic Fiber Board** is crafted from refractory fiber pulp, incorporating only the minimal amount of organic or bio-based bonding agents to ensure purity and performance.

2. Any initial smoke generated during the heating of the Ceramic Fiber Board is a transient phenomenon and does not compromise its superior high-temperature insulation capabilities.

3. The Ceramic Fiber Board is extensively utilized in various industries for its exceptional insulation properties, particularly in applications requiring high-temperature insulation solutions.

High-Performance Ceramic Fiber Insulation Board

Detail Image

Product Details

DescriptionGrade		COM	STD	HP	HA	HZ
TENGLONG style		4110COM	4110STD	4110HP	4110HA	4110HZ
Classification Temperature	English	2012℉	2300℉	2300℉	2480℉	2606℉
Classification Temperature	Metric	1100℃	1260℃	1260℃	1360℃	1430℃
Max Working Temperature	English	1832℉	1832℉	1832℉	2192℉	2462℉
Max Working Temperature	Metric	1000℃	1000℃	1100℃	1200℃	1350℃
Density	English	19 lb/ft3
Density	Metric	300kg/m3
Specification	English	23.62×15.75×0.79-1.97inch; 35.43×23.62×0.79-1.97inch; 283.47×12.20×0.39-1.97inch
Specification	Metric	600×400×20-50mm; 900×600×20-50mm; 7200×610×10-50mm

Features
·Resists abrasion
·Resists most acids and alkalis
·Strong and durable
·Not affected by solvents or bleaches

Specification(mm):600*400*20-50;900*600*20-50,other made according to customers' requirement.

More Styles

Application Data

Advantages

Video

Comparison Vision

DescriptionGrade		COM	STD	HP	HA	HZ
TENGLONG Style		4110COM	4110STD	4110HP	4110HA	4110HZ
Classification Temperature	English	2012℉	2300℉	2300℉	2480℉	2606℉
Classification Temperature	Metric	1100℃	1260℃	1260℃	1360℃	1430℃
Rate of Liner		-4%	-3%	-3%	-3%	-3%
Rate of Liner		1000℃	1000℃	1000℃	1200℃	1350℃
Tensile Strength	MPa (128kg/m3)	0.5	0.5	0.5	0.5	0.5
Water Content		≤1%	≤1%	≤1%	≤1%	≤1%
Loss of Ignition		≤7%	≤7%	≤7%	≤7%	≤7%
Chemical Composition	Al2O3	44%	46%	47-49%	52-55%	39-40%
	Al2O3+SiO2	96%	97%	99%	99%	-
	Al2O3+SiO2+ ZrO2	-	-	-	-	99%
	Zr02	-	-	-	-	15-17%
	Fe2O3	<1.2%	<1.0%	0.20%	0.20%	0.20%
	Na2O+K2O	<=0.5%	<=0.5%	0.20%	0.20%	0.20%

-Hot air duct lining
-Shuttle kiln with high gas velocity
-Laboratory furnace
-Kiln car insulation
-Die-cut high temperature seal

Simply you can wholesale High-Performance Ceramic Fiber Insulation Board direct from manufacturers.

Professional Manufacturer

SUNPASS SEALING i a leading manufacturer in Sealing and Insulation in China. Production & Service 7*24 . Sunpass is a famous Chinese brand and High-Performance Ceramic Fiber Insulation Board suppliers known by the world since 2000.
